Brand Name : | CR |
Model Number : | UTF01 |
Certification : | CE ISO9001 |
Price : | USD1500/PCS |
Payment Terms : | T/T |
Supply Ability : | 1000PCS/month |
Delivery Time : | 8 |
Specifications | ||
Model | UTF01 | |
Pump head | YZ1515x | |
Channel number | 4 is standard | Max 32 channels |
Pump head in series | 1 is standard | Max 2 heads for each channels |
Filling volume | 0.1ml-9999.99ml/time | Display adjustment resolution: 0.01ml |
Filling time | 0.1s-9999.9s/time | Display adjustment resolution: 0.1s |
Filling times | 0-9999time | "0" is an infinite loop |
Back suction speed | 0-1000° | Display adjustment resolution: 1° |
Back suction delay | 0-300rpm | Display adjustment resolution: 1rpm |
Interval time | 0.5s-9999.9s/time | Display adjustment resolution: 0.1s |
Channels number | channel / unit (standard),23456 channel / unit (optional) | Scalable up to 32N4 |
Back suction delay | 0s-60s | Display adjustment resolution: 0.1s |
Power supply | 220v or 110v optional | |
External Control | start-stop cable // No bottle no filling function can work with
your sensor or PLC. |
![]() |
